- General Information
- Manufacturer
- CommScope, Inc
- Manufacturer Website Address
- http://www.commscope.com
- Brand Name
- RUCKUS
- Product Series
- ICX 7150
- Product Type
- Ethernet Switch
RUCKUS ICX 7150 Switches
The standard RUCKUS ICX 7150 switches are available in 24-, and 48-port 10/100/1000 Mbps models with four 1/10 GbE dual-purpose uplink/stacking ports. These switches are available with or without PoE+ power. Silent operation is available for out-of-closet environments.
- Technical Information
- Features
- Fanless
- In-Service Software Upgrade (ISSU)
- Access Control List
- Energy Efficient
- Interfaces/Ports
- Total Number of Network Ports
- 50
- Uplink Port
- Yes
- Modular
- Yes
- Stack Port
- Yes
- Network (RJ-45)
- Yes
- Port/Expansion Slot Details
- 48 x Gigabit Ethernet PoE
- 2 x Gigabit Ethernet Uplink
- 4 x 10 Gigabit Ethernet Expansion Slot
- Media & Performance
- Media Type Supported
- Twisted Pair
- Optical Fiber
- Ethernet Technology
- Gigabit Ethernet
- 10 Gigabit Ethernet
- Network Technology
- 10/100/1000Base-T
- 10GBase-X
- I/O Expansions
- Total Number of Expansion Slots
- 4
- Expansion Slot Type
- SFP+
- Number of SFP+ Slots
- 4
- Network & Communication
- Layer Supported
- 3
- Networking Standards
- IEEE 802.3ad
- IEEE 802.3ae
- IEEE 802.3bz
- IEEE 802.3u
- IEEE 802.3x
- IEEE 802.3z
- IEEE 802.1Q
- IEEE 802.1br
- IEEE 802.3af
- IEEE 802.3at
- IEEE 802.1p
- IEEE 802.1x
- IEEE 802.1s
- IEEE 802.1ab
- IEEE 802.1D
- IEEE 802.1w (RSTP)
- IEEE 802.3
- IEEE 802.3ab
- Management & Protocols
- Manageable
- Yes
- Reliability
- MTBF
- 312241 Hour
- Power Description
- PoE (RJ-45) Port
- Yes
- PoE Budget
- 740 W
- Power Source
- Power Supply
- Redundant Power Supply Supported
- No
- Number of Power Supplies Supported
- 1
- Number of Power Supplies Installed
- 1
- Power Consumption
- 24 W
- Plug/Connector Type
- C14
- Physical Characteristics
- Color Family
- Black
- Product Color
- Black
- Compatible Rack Unit
- 1U
- Form Factor
- DIN Rail Mountable
- Desktop
- Height
- 43.7 mm
- Width
- 440 mm
- Depth
- 370 mm
- Weight (Approximate)
- 6.28 kg
- Miscellaneous
- Application/Usage
- Network
- Enterprise
