- General Information
- Manufacturer
- Opengear
- Manufacturer Website Address
- http://www.opengear.com
- Brand Name
- Opengear
- Product Series
- CM8000
- Marketing Information
Compact Console Server with Serial Access and PDU Integration for Edge and Remote Sites
Reliable serial console and power access for branch offices, retail locations, network closets, and remote edge environments, even when the network is down.
The CM8000 Console Manager is a compact, purpose-built console manager designed to keep critical infrastructure reachable when everything else is out. Built on a powerful quad-core ARM platform, the CM8000 delivers secure serial console access and serial density in a small form-factor to support rapid recovery across distributed and remote sites.
Designed for environments where space is limited but uptime is critical, the CM8000 provides reliable out-of-band access to network devices, servers, and infrastructure equipment.
- 4 or 8 port Cisco Straight X2 pinout serial ports, with Smart Out-of-Band™
- Integrated PDU support for remote power control
- Secure, audited serial console access
- Quad-core ARM platform for reliable performance
- Compact form factor optimized for space-constrained deployments
- Seamless integration with Opengear Lighthouse® for centralized management
- Product Type
- Device Server
- Warranty
- Limited Warranty
- 5 Year
- Additional Warranty Information
5 years hardware replacement included. Appliance requires a minimum of 1 year Foundation Support at the time of purchase.
- Technical Information
- Device Type
- Console Server
- Connectivity Technology
- Wired
- Processor & Chipset
- Processor Manufacturer
- ARM
- Processor Speed
- 1.60 GHz
- Memory
- Standard Memory
- 3.91 GB
- Media & Performance
- Media Type Supported
- Twisted Pair
- Optical Fiber
- I/O Expansions
- Total Number of Expansion Slots
- 2
- Expansion Slot Type
- SFP
- Network & Communication
- Ethernet Technology
- Gigabit Ethernet
- Network Standard
- 1000Base-T
- 100Base-TX
- Interfaces/Ports
- Network (RJ-45)
- Yes
- USB
- Yes
- Serial Port
- Yes
- Management Port
- Yes
- Total Number of Network Ports
- 2
- Number of Network (RJ-45) Ports
- 2
- Number of USB Ports
- 2
- Number of Serial Ports
- 8
- Environmental Conditions
- Minimum Operating Temperature
- 5°C
- Maximum Operating Temperature
- 50°C
- Power Description
- Input Voltage
- 120 V AC
- 230 V AC
- 12 V DC
- Input Voltage Range
- 110 V AC - 240 V AC
- Power Consumption
- 24 W
- Physical Characteristics
- Form Factor
- Rack-mountable
- Compact
- Height
- 44.4 mm
- Width
- 220 mm
- Depth
- 177.8 mm
- Weight (Approximate)
- 1.25 kg
- Miscellaneous
- Package Contents
- CM8000 Console Manager
- Rack Mount Kit
- C14 Power Cable
- A/C Power Brick
- Certifications & Standards
- IEC 62368-1:2023
- 47 CFR Parts: 15B
- ICES-003 Issue 7
- EN55032:2015+A11:2020
- EN 301 489-1:2019 v.2.2.3
- EN 301 489-52:2021 v.1.2.1
- EN55035:2017+A11:2020
- IEC 61000-3-2:2018+A2:2024
- EN 61000-3-2:2019+A2:2024
- IEC 61000-3-3:2013+A2:2021
- EN 61000-3- 3:2013+A2:2021
- EN 63000:2018
- KS C 9832:2019
- KS C 9835:2019
- AS/NZ CISPR 32:2015
- VCCI-CISPR 32:2016
- CNS 15936:2016
- IEC 62368
- UL
- CB
- DoE, VI, PSE
- LPS certified
- Environmental Compliance
- Restriction of Hazardous Substances (RoHS)
